KD2505 S-01 Front Brake Pads - Lexus RX

Barbaro Racing KD2505 S-01 front brake pads for Lexus RX / NX / LM / ES, Toyota Highlander / Alphard Hybrid / Sienna / Vellfire Hybrid / RAV 4 IV / Kluger. S-01 is Barbaro's semi-metallic street and track-day compound (800°C, μ 0.35–0.50). Pad shape KD2505: 167.2 × 59.4 × 17.6 mm; interchanges with FMSI D1324, TRW GDB3484, Brembo P83145N.

Specifications

Barbaro part number	KD2505
Compound	S-01 — Semi-metallic
Barbaro factory code (SKU)	D25050N6
Axle	Front
Dimensions (L × H × T)	167.2 × 59.4 × 17.6 mm
Friction material height	53.1 mm
Supplied as	One axle set
Also available for KD2505	KD2505 C-01 Premium Street

Vehicle fitment

Make	Model	Chassis	Years	Engine / variant	Notes
Lexus	ES	AVV6, GSV6, ASV6	2012–	350, 3.5 (2GR-FE)	Advics calipers
Lexus	LM		2019–	2.5L hybrid
Lexus	NX	AZ10, ZGZ1, AGZ1, AYZ1	2014–	2.0T, 2.5L hybrid, 200, 200t, 200t AWD, 300h, 300h AWD, 2.5 hybrid (2AR-FXE), 2.0 (3ZR-FAE), 2.0 (8AR-FTS)	Advics calipers
Lexus	RX	AL20, AL10, GGL1, GYL1, AGL1	2008–	2.0T, 3.5L hybrid, 270, 350, 350 AWD, 450h, 450h AWD, GYL10, GYL15, 2.7 (1AR-FE) …	Advics calipers
Toyota	Alphard Hybrid	AH30	2018–	2.5L hybrid
Toyota	Highlander	XU40, MHU4, GSU4, ASU4	2007–	3.3L, 3.3L hybrid, 3.5 4WD, 3.5 (2GR-FE), 2.7 VVTi, 2.7 VVTi 4WD, 2.7 (1AR-FE)	Advics calipers
Toyota	Kluger	MHU4, GSU4, ASU4	2007–	3.5 4WD, 3.5 (2GR-FE), 2.7 VVTi, 2.7 VVTi 4WD, 2.7 (1AR-FE)	Advics calipers
Toyota	RAV 4 IV	WWA4, AVA4, ZSA4, ALA4	2012–	2.0 D4-D, 2.0 D-4D, 2.0 D4-D 4WD, 2.2 D4-D 4WD, 2.0 diesel (1AD-FTV), 2.2 diesel (2AD-FHV), 2.2 diesel (2AD-FTV), 2.0 diesel (2WW), 2.0 VVT-i 4WD, 2.0 (3ZR-FAE)	Advics calipers
Toyota	Sienna	XL30, ASL3, GSL3	2010–	3.5 VVTi 4WD, 2.7 (1AR-FE), 3.5 (2GR-FE), 3.5 VVTi	Advics calipers
Toyota	Sienna Mini Cargo		2011–	3.5 (2GR-FE)
Toyota	Vellfire Hybrid	AH30	2018–	2.5L hybrid
Toyota	Highlander (China · GAC Toyota)	XU40, XU50	2008–	2.0T, 3.5 4WD, 2.7 (1AR-FE), 2.7 (3AR-FE), 3.5 (2GR-FE), 2.0 (8AR-FTS)

Fitment is compiled from the Barbaro Racing application catalogue and Barbaro factory data, together with the vehicle listings of the interchange part numbers below. Brake packages can differ within one model — please compare your current pads with the dimensions and drawing, or send us your VIN, before ordering.

Cross-reference / interchange numbers

FMSI	D1324, D1324-8436, D1324-9108, D1567-8776
TRW	GDB3484
Brembo	P83145N, P83145
PAGID	T1997
Ferodo	FDB4354
Textar	2445201, 2445203, TX1096
Mintex	MDB3114, MDB83114
Bosch	0986494686, 0986AB2846, 0986AB3746, 0986AB1090, 0986495169
ATE	13.0460-5634.2, 13.0470-5634.2
Delphi	LP2201
Bendix	572655B, DB2004
Jurid	572655J, 572655JC
Hella Pagid	8DB355015461, 355024491, 8DB355024491
Akebono	ACT1324
Icer	181982
Remsa	1312.00
WVA	24452
OE Lexus	0446548160, 0446548170, 0446548150, 044650E010, 0446548190
OE Toyota	044650E010, 0446548170, 0446548190, 0446548150, 0446548160

Interchange numbers identify the matching pad shape. Friction material, shims and wear-sensor hardware can differ between brands.

About the S-01 compound

S-01 · Where street meets track

Semi-metallic compound for street performance and track-day duty. Superior controlled deceleration at speed, excellent noise compatibility — and proven on the rear axle of professional race cars.

Temperature rating: 800°C
Friction: μ 0.35–0.50
Formula: Semi-metallic
800°C maximum temperature rating
Street-legal track day capability
Superior high-speed deceleration control
Pro-level rear axle performance
Ideal for: Track days, heavy high-performance street cars and race-car rear axles

S-01 full specifications on barbaro-racing.com

About Barbaro Racing

Barbaro Racing (野蛮人) is the performance brand of the CAC Racing Division — proprietary compounds developed entirely in-house. Development begins on the dynamometer and ends on the circuit: every friction formula is bench-tested to destruction before earning the right to carry the Barbaro name. All compounds are validated against GB5763-2018 national standards; Street Series compounds are asbestos-free.
