KD5010H RS-635 Front Brake Pads - Endless EC690

Barbaro Racing KD5010H RS-635 front brake pads for Endless EC690, Minsheng GP02, AP Racing CP9665 calipers. RS-635 is Barbaro's low-metallic endurance race compound (50–800°C, μ 0.40–0.52) — CEC 2025 TCS class winner. Pad shape KD5010H: 162.9 × 68.6 × 20 mm; interchanges with Ferodo Racing FRP3039.

Specifications

Barbaro part number	KD5010H
Compound	RS-635 — Race endurance low-metallic
Barbaro factory code (SKU)	D5010H2N5
Axle	Front
Dimensions (L × H × T)	162.9 × 68.6 × 20 mm
Drawing note	Drawing is rotated (long side vertical): length = vertical dimension, height = horizontal dimension. 162.9 overall (153 on the other side); 40.1 inner width; backing plate 6; friction 54.
Supplied as	One axle set
Pad features	20 mm thick

Caliper fitment

Caliper brand	Caliper	Details
Endless	EC690	54 mm friction face, 20 mm thick
Minsheng	GP02	20 mm thick
AP Racing	CP9665	20 mm thick

Fitment is compiled from the Barbaro Racing application catalogue and Barbaro factory data, together with the vehicle listings of the interchange part numbers below. Brake packages can differ within one model — please compare your current pads with the dimensions and drawing, or send us your VIN, before ordering.

Cross-reference / interchange numbers

Ferodo Racing	FRP3039

Interchange numbers identify the matching pad shape. Friction material, shims and wear-sensor hardware can differ between brands.

About the RS-635 compound

RS-635 · The endurance champion

The CEC 2025 class winner. At Tianfu International Circuit, a Hongqi H6 on RS-635 ran a 200-minute stint against PAGID RST3's 120 — with less wear.

Temperature range: 50–800°C
Friction: μ 0.40–0.52 (steel disc)
Formula: Race endurance low-metallic
Discs: Steel and carbon-ceramic
CEC Championship validated — TCS class winner
200 min endurance on a single set
Ideal for: Endurance racing in heavier GTC and touring cars

RS-635 full specifications on barbaro-racing.com
